Motor: 900W
Input: 230-240V ~ 50Hz
No load speed: 1000/min
Blade length: 410mm
Max. blade capacity: 18mm
Weight (tool only): 6.05kgs
1. Blade
2. Gearbox
3. Blade adjustment locking knob
4. Angle Head locking mechanism
5. Upper locking lever
6. Lower locking lever
7. Blade angle adjustment handle
8. Upper shaft
9. Shaft locking knob
10. Adjustable auxiliar
y straight handle
11. Adjustable auxiliar
y D-handle
12. Lower shaft
13. Safety slide
14. Shoulder strap attachment bracket
15. Rotating handle lock
16. Lock off switch
17. On/of
f button
18. Rear handle
19. Extension cor
d restraint
20. Blade cover
21. Shoulder strap
22. Auxiliar
y handle bracket
2
SPECIFICATIONS - MODEL NO. PHT-410
3
1
6
KNOW YOUR PRODUCT
19
20
5
11
15
7
2
4
9
14
18
16
17
13
12
10
8
21
22
