ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 Collet Nut
2 Shaft Collar
3 Spindle Lock Button
4 Accessible Brushes
5 Variable Speed Dial
6 On/off Switch
7 Hanging Ring
8 Power Cord
ROTARY TOOL
KNOW YOUR PRODUCT
1. CHANGING ACCESSORIES
9 Flexible Shaft
10 Locking Chuck
11 Spindle Lock
12 Fitting Collar
13 Spindle Lock Key
14 Rotary Bits x 106
15 Spanner
ACCESSORIES
SETUP & PREPARATION
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
WARNING! ENSURE THE TOOL IS DISCONNECTED
FROM THE POWER SUPPLY BEFORE PERFORMING ANY
OF THE FOLLOWING OPERATIONS.
1 Press and hold the spindle
lock button.
2 Unscrew the collet nut and
remove completely.
3 Select a suitable collet for
the accessory to be used
and insert. Then cover
with collet nut.
4 Lightly tighten the collet nut so
that it stays in place.
5 Insert shaft of accessory
into the collet.
6 Tighten collet nut using spindle
lock and spanner.
