Ozotech AIO3 Systems - Installation of EOG Unit

-1-
AIO-OZONE Installation & Programming Guide
Step 1: For both the Ozotech & Nelsen EOG Models: Unplug
the power supply for the control valve from the wall outlet.
Step 2: Remove the cover from the control valve, Photo A.
Installation of EOG Unit (For Dealer Install Kits)
Photo D
Thumbs Push Up on Tabs
Forefingers
Here
Photo A
Photo B
Photo C
Step 4: For the Nelsen EOG Model, Reference 2 on previ-
ous page, disconnect the power supply from the control
board, Photo C.
Step 5: Unsnap the top of the drive bracket using your
thumbs and forefingers to expose the backplate. Remove
the power supply by pulling it through the back of the
backplate, Photo D.
Step 3: For the Ozotech EOG Model, Reference 1 on
previous page, leave the power supply connected to the
control board, Photo B. Move to Step 6
