23
1
First mount the lamp holder: slide
the provided lamp holder from the
top to the bottom of the lamp holder
adapter positioned on the sides
covers (left/right) of the helmet. Make
sure the lamp holder is rmly placed
and positioned as shown in the
2
Mount the lamp: slide the lamp into
the lamp holder through the gap on
the side (PELI lamp) or from the front
of the lamp holder (UK 4AA or 2AA)
Type I lamp holder (open lamp holder for UK Underwater Kinetics and PELI lamps)
3
To adjust the lamp angle, turn the
lamp clockwise or counter clockwise
Picture 26
Picture 27
