Xi3 (PX031ANI) USER GUIDE DRAFT (501-340120x)
CONNECTING THE EQUIPMENT (cont.)
Setup - HDTV (HDMI connection)
this set uses an HDMI connector to connect to the HDTV. This displays the highest quality picture on your HDTV and also means there will be no picture
degradation on any copy-protected programs (provided the link remains secure – see page 7).
