No Item Definition
1. L-Sharp cradle cable for MDT-801 (CAB-CRD865-BASIC)
L-Sharp cradle cable assignment overview
The Basic feature extension cable (CAB-EX-BASIC) is optional.
L-Sharp cradle cable can be used for both full and basic feature cradle (MDT-801)
P1
P2
Cradle
Connector
9 pin BMW
Connector F
Pin1 Pin2
Shield VideoTrigger
Pin12
Camera DC12V output
Pin1
VCC 12-32V input
Pin5 Pin6
RXD TXD
Pin3
ACC ignition
Pin13
VCC 12-32V input
Pin2
ACC ignition
Pin7 Pin8
Pin8 Pin9 Pin11
RXD GND Video input
Pin18
TXD
Pin3 Pin4
Video Trigger Video input
Pin9
Camera DC12V output
This is the L-sharp cable (thickness around 25mm)
Shield GND
