How it Works:
To evacuate air from the cooking area, air
is drawn in through the grilles by the suc-
tion fans, spun at high velocity where
grease and residue are separated and de-
posited into the residue cups. The cleansed
air is then forced out through the external
duct work into the outside environment.
Easy to use Rocker Switch Controls
mounted on the front of the unit, provide
two speed settings for each fan and on-off
control for the light.
The controls shown below are located on
the front panel of the unit.
Each fan has its own rocker
switch speed control to match the require-
ment for air extraction in all situations.
For proper care and
maintenance of your range
hood, refer to page 10.
Operating the AK-9800/EP-9800 Operating Guidelines
The Light rocker switch positions are:
OFF ON
HI OFF LO
The Fan rocker switch positions are:
AK-9800/EP-9800
