Pack Leader ELF-20 - Page 47

|
47
APPLICATOR UP/DOWN ADJUSTMENT
ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Mounting Base Of Hand Wheel
AA1-ELF-014
1
2
Screw Rod M16300
AA1-ELF-007
1
3
Nylon Washer
2FN2-101610
6
4
Applicator Shaft Clamp
AA1-ELF-002B
4
5
Right Angle Seat
AA1-ELF-009
2
6
Transfer Sleeve Of Shaft
AA1-ELF-003
2
7
Hand Wheel
QRGX-KRA100CB65
1
8
Socket Head Cap Screws
XNJW-M512
2
9
Socket Head Cap Screws
XNJW-M625
8
10
Socket Head Cap Screws
XNJW-M640
4
11
Socket Head Cap Screws
XNJW-M635
4
12
Sliding Shaft
AA1-ELF-016
2
13
Screw Base
AA1-ELF-010
1
14
Socket Head Cap Screws
XNJW-M620
2
