Pack Leader ELF-20 - Conveyor Motor Assembly

|
52
CONVEYOR MOTOR ASSEMBLY
CONVEYOR MOTOR ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
3 Phase Stepper Motor
A2EU-51K40GNST
1
2
Gear Reducer 5GN15K
A2RG-5GN15K-1
1
3
Double Head Round Keys
RGM-4425
1
4
Pulley
CV1-ELF-017
1
5
Socket Set Screw
XN5Z-M45
1
6
Spring Washer
2FWO-M6
4
7
Socket Head Cap Screws
XNJW-M675
2
8
Socket Head Cap Screws
XNJW-M685
2
