Pack Leader ELF-20 - Applicator Front;Rear Adjustment Assembly

|
48
APPLICATOR FRONT/REAR
ADJUSTMENT ASSEMBLY
APPLICATOR ADJUSTMENT
ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Hand Wheel
QRGX-KRA100CB65
1
2
Socket Head Cap Screws
XNJW-M512
2
3
Mounting Base Of Hand Wheel
AA1-ELF-014
1
4
Sliding Shaft D20400
AA1-ELF-004
2
5
Applicator Sliding Base
AA1-ELF-001B
1
6
Self Run Bearing
5TDU-LBF2015
4
7
Socket Head Cap Screws
XNJW-M620
2
8
Nylon Washer
2FN2-101610
6
9
Screw Rod
AA1-ELF-007
1
