FOOT STAND ASSEMBLY PART LIST
NO.
DESCRIPTION
PARTS NO.
QTY.
1
Top Cover
CS1-ELF-006
1
2
Control Box Panel Fixed Plate (Left)
FT1-ELF-022
1
3
Control Box Panel Fixed Plate (Right)
FT1-ELF-021
1
4
Panel
CS1-ELF-002B
1
5
Base
CS1-ELF-001C
1
6
Stand Connector - Front Left
FT1-ELF-032
1
7
Stand Connector - Front Right
FT1-ELF-033
1
8
Plug
QVDG-HP13
12
9
Pad
51WR-NS401285
4
10
Stand Connector
FT1-ELF-014C
2
11
Conveyor Fixed Supporter (Outer)
FT1-ELF-017C
4
12
Conveyor Supporter - Left
FT1-ELF-024E
2
13
Conveyor Fixed Supporter (Inner)
FT1-ELF-018D
4
14
Back Stand Connector
FT1-ELF-034C
1
15
Aluminum Extrusion
FT1-ELF-035
2
16
Conveyor Supporter - Right
FT1-ELF-023E
2
17
Supporter Connecting Base
FT1-ELF-025C
1
18
Supporter Connecting Base (Inner)
FT1-ELF-026C
1
