8 RX3i Ethernet NIU
GFK-2419M
Functional Compatibility
Product Compatible Versions
Proficy® Machine Edition Logic
Developer
Proficy® Machine Edition Logic Developer 5.9 SIM1 or later versions required to use
the new Release 5.70 features with the RX3i CPU.
Proficy® Machine Edition Logic Developer 5.9 is required to use Release 5.60
features with the RX3i CPU.
Proficy® Machine Edition Logic Developer 5.8 is required to use Release 5.50
features with the RX3i CPU.
Proficy® Machine Edition Logic Developer 5.7 is required to use Release 5.0
features with the RX3i CPU.
Machine Edition Logic Developer 5.5 with Service Pack 1 is required to use the eight
ETM feature with the RX3i Ethernet NIU.
Release 5.5 SIM 1 or later is required to enable use of the RX3i Ethernet NIU.
C Toolkit Compatibility C Toolkit Release 5.50 is required to use the LREAL data type.
All C blocks must be recompiled using the new toolkit before downloading to a CPU
that contains Release 5.00 firmware.
Backplanes, power supplies, and
system modules
As listed in the PACSystems RC3i System Manual, GFK-2314C or later.
New NIU Features and Enhancements in Release 5.70
New Module Supported
 This release enables support that is functionally identical to the IC695CMX128 for the IC695RMX128 on all Rx3i
CPUs (CPU310, CPU320, CRU320, NIU001, and CMU310.)
Restrictions and Open Issues in this Release
Subject Description
The Ethernet module fails to
exchange EGD properly
during power cycling
Very rarely, after experiencing multiple rapid power cycles, the CPU may fail to
establish communication with one or more modules in the backplane at power up.
When this occurs a "Loss of” or “missing option module" fault will be logged in the
controller fault table. To recover from this issue, cycle power again.
The following faults will be logged if this issue occurs:
Loss of, or missing option module
Error Code 31
Group 4
Action 3:Fatal
Task Num 9
Reset of option module
Error Code 11
Group 8
Action 2:Diagnostic
Task Num 9
Loss of, or missing option module
Error Code 94
Group 4
Action 3:Fatal
Task Num 9
Switching between Serial &
PCI modules in a slot causes
module to not be recognized.
If a Serial module (IC694) is physically installed in the slot where a PCI (IC695)
module is configured, a module mismatch fault will be logged.
To correct this condition the configuration must match the module that is physically
present in the rack
and the system must be power cycled. Simply downloading the
new configuration will not correct this issue.
