Section 1 - Overview
Section 1 gives a brief overview of the T6M mobile transceiver.
About this User Guide
This user guide describes the purpose, installation, and operation of the
Park Air Electronics (PAE) T6M mobile transceiver. How to programme the required
channel frequencies and operating modes using the optional programming kit is also
fully described.
Introduction to the T6M Mobile Transceiver
The T6M multichannel mobile transceiver provides communication within the VHF
aeronautical frequency band 118 to 136.9916 MHz. The transceiver provides a nominal
8 watt amplitude modulated (AM) output, and operates on both 25 kHz and 8.33 kHz
spaced channel frequencies.
Designed for installation within a vehicle, the transceiver operates from a +13.2 volt dc
supply. For vehicles that use a 24 V dc system, or when there must be isolation
between the battery and equipment, a suitable dc to dc converter must be used.
Operating Modes
Three operating modes are available: Normal, Priority, and Scan.
Normal Mode
In normal mode, any channel frequency programmed into the transceiver can be
selected using the front panel keys. Up to 760 channel frequencies can be programmed
into the radio's personality.
T6M User Guide
Page 9
