PAL EVENGLOW - Niche Installation; Securing to Steel Bars

NICHE INSTALLATION
Securing to steel bars
20 or 25mm conduit using PVC solvent cement
3
Secure niche to steel reinforcing bars using wire
in 4 positions
70mm (MAX)
50mm (MIN)
20mm
(MAX)
50mm (MIN)
CONCRETE
COVERAGE
Wipe around niche perimeter and ll with 2 pack
bonding to seal plastic to concrete
Niche can be trimmed if sticking out from
concrete shell max 20mm
