PAL EVENGLOW - Cable Installation

NICHE INSTALLATION
Installation of cable
2 METRES (MAX)
700mm (MIN)
1. Remove Niche protective cap
2. Draw cable through conduit
3. Tighten cable nut by hand only
Rubber Grommet
Niche installed in
wall
Cable and plug
assembly
Cable nut
N.B. Do not remove
protective cap until
installation of light
4
