9
Quick set-up
46
Subject to change without notice
9 Quick set-up
Short introduction for quickly setting-up the machine:
More detailed information can be found on the pages indicated.
9.1 Mechanical set-up
1. Set up machine to the previous machine and lock the adjusting feet Page 25
2. Adjust delivery’s height Page 25
3. Call up one product from the folding machine or saddle stitcher
and adjust round belts Page 20
4. Set infeed photocell Page 19
5. Adjust pressing unit Page 31
- Folding machine 1. Pre press roller 75%
2. Main press roller 50%
- Saddle stitcher 1. Pre press roller 125%
2. Main press roller approx. 100% or more
Controls:
1. Press calibrate key Page 37
2. Call up product
3. Press auto calibrate key Page32
6. Call up the product and allow it to run up to the shaft by
pressing the rocker switch. Page 37
7. Adjust lateral jogging plates to the product. Page 37
8. Adjust adjusting frame to the product width Page 34
9. Adjust support finger under the product edges. Page 34
9.2 Controls
1. Enter amount Page 39
2. Set total counter to zero Page 41
3. Select single sheet or shingled stream depending on
the product and speed. Page 42
4. Align the round belt’s speed on the folding machine
or saddle stitcher +/-. 10%. Page 30
