17
ENGLISH
ADJUSTING REAR FANS
At installation time you can adjust the ow rate of
the rear fans according to the type of distribution
system created (length, cross section, materials
used ...).
Once you start up the heater and switch on rear
fans from the ventilation menu, adjust rear fans
by acting on the potentiometers on the back of
the stove (see Figure 1.1-D) until you reach the
desired level of ventilation.
It is possible to connect two external thermostats
to the terminal block of the heater so as to be able
to switch on and o the rear fans according to the
temperature set on the thermostats.
To take advantage of this feature, the ventilation of
the two rear fans should be set to ON.
The thermostat which controls the Left fan should
be connected to terminals 3 and 4 of the terminal
block.
The thermostat which controls the Right fan
should be connected to terminals 5 and 6 of the
terminal block.
D
