2 CoNNECToRS & CONTROLS:
9 DRIVE VOLUME
This controls the volume of the DRIVE channel (use to balance or match with the CLEAN volume).
10 DRIVE PRESENCE
This controls the upper midrange/high frequency response of the power amp when the DRIVE channel is selected.
11 DRIVE/CLEAN
This switches between the DRIVE and CLEAN channels. The red LED lights when the DRIVE channel is selected.
This function is also footswitchable. Connecting the dedicated Palmer 4-on-the-oor switch to the “Channel
Select“ socket on the rear panel defeats the front panel switch.
12 REVERB
This controls the amount of reverb mixed in with the direct signal. The integrated spring reverb can be switched
ON and OFF with the dedicated Palmer 4-on-the-oor switch.
13 MASTER
This controls the overall output level of the amp.
14 PILOT LAMP
This lights when the amp is switched on (and the correct mains power is present).
15 POWER
This is the ON/OFF switch for powering the amplier.
16 STANDBY
Turn on this switch 3 – 4 minutes after turning on the power switch. The standby function enables the tubes to
attain proper operating temperature and prolongs tube life. Also, use this switch to mute the amp between sets
while keeping the tubes at operating temperature.
