7 TECHNICAL SPECIFICATIONS:
INPUT SECTION:
INPUT
1/4“ TS (6.3mm) unbalanced
INPUT IMPEDANCE: 1 MOhm
SENSITIVITY: -10 dBV
MAX. INPUT LEVEL: +6 dBV
FX SEND
1/4“ TS (6.3mm) unbalanced
OUTPUT IMPEDANCE: 1 kOhm
OUTPUT LEVEL: -6 dBV
Max. output level: 0 dBV
FX RETURN
1/4“ TS (6.3mm) unbalanced
INPUT IMPEDANCE: 16 kOhms
SENSITIVITY: -10 dBV
Max. input level: 0 DBV
TUBES:
PREAMP
V1, V2: ECC83/ 12AX7A, high grade
V3, V4: ECC83/ 12AX7A, selected
POWER AMP
V5, V6: 5881 (6L6GC), matched set
OUTPUT: 50 Watt @ 8 or 16 Ohms
LOUDSPEAKER (COMBO ONLY)
12” Eminence Governor, 16 Ohms
ADDITIONAL SPECIFICATIONS
MAINS: 230 V AC +/-10%
MAX. POWER CONSUMPTION: 150 W
POWER CONSUMPTION @ STANDBY: 42W
MAINS FUSE: 250V/ T 1 A (slo-blo)
ANODE FUSE: 250V/ T 500mA (slo-blo)
HEATER FUSE: 250V/ T 5 A (slo-blo)
CAUTION! Replace fuses with IEC type 127 (5 x 20 mm)
and specified rating only!
RECOMMENDED OPERATING ENVIRONMENT: 0 - +35° C
COMBO
DIMENSIONS (W X H X D): 580 x 500 x 270 mm
WEIGHT 30 kg
HEAD
MASSE (W X H X D): 580 x 270 x 270 mm
WEIGHT: 25 kg
Since all our products are constantly controlled
and improved, technical changes are possible
without prior notice.
