CALDERA E CORTEN FIRE PIT | Owner and Installation Manual
CLEANING AND MAINTENANCE
WARNING: Turn o gas before servicing re pit. It is recommended that
a qualied service technician perform these check-ups at the beginning
of each re pit season.
If any irregularities are apparent with operation. Please refer to Troubleshooting
guide, pages 11-12.
BURNER ELEMENT AND PILOT
Keep the burner and pilot area clean by vacuuming or brushing at least twice a year.
Make sure the burner porting and burner air openings are free of obstructions at all
times.
Inspect area around the burner. Remove any lint or foreign material with a brush or
vacuum cleaner.
If it evident that the burner is damaged, the burner must be replaced prior to the
appliance being put into operation.
PILOT FLAME
The ames from the pilot should be
visually checked as soon as the unit
is installed, and periodically during
normal operation. The pilot ame
must always be present when the
replace is in operation or connected
to the gas line with the main shuto
valve open and the IPS activated
(powered). The pilot ame has two
distinct ames: one engulng the
ame sensor, and the other reaching
to the main burner.
Burner Element
Pilot Assembly
