6295-6298 ENCLOSED HEAT DETECTOR - FIRE ALARM SOLUTIONS TECHNICAL DESCRIPTION
5
3. GENERAL DESCRIPTION
The heat detectors are conventional xed temperature heat detectors. The detectors will give an alarm at a certain xed tempera-
ture (57 °C / 72 °C / 87 °C / 117 °C).
The detector is intended for outdoor use or indoor use in high humidity premises.
2
1
75
10095
(Measure in mm)
1. Detector
2. Connection box
3.1. DETECTOR
The sensing element is a heat pick-up shield and a bimetal switch.
The detectors will give an alarm within a response temperature range in accordance with EN54-5, see table below.
Type Static response temperature Category
6295 57 °C A2 S
6296 72 °C B S
6297 87 °C C S
9298 117 °C E S
3.1.1. LATCHING
The detector is latching. The detector will not be automatically reset if the temperature, after the alarm, falls below the detector's
static response temperature. The detector's LED and a connected external LED will be lit until the detector is reset via the CIE.
