Panasonic AG-MX70 - [3 Dmodify] Setting

40
Effect-by-effect setting screens
3D
Modify
Rotate
128
Time
0
TransF
255
0 - 255
0 - 255 0 - 255
3D
Modify
Width
192
Angle
96
Time
48
Amp
32
0 - 255
0 - 255 0 - 255 0 - 255
3D
Modify
Width
160
Angle
96
Amp
48
0 - 255
0 - 255 0 - 255
3D
Modify
Rotate
128
Axis
0
View
128
Depth
64
0 - 255
0 - 255 0 - 255 0 - 255
[3Dmodify] setting
This takes effect only for the special 3D patterns (numbers 6001 to 6438 and 6601 to 6716) when the 3D optional board (AG-
VE70) has been installed.
The parameters of the pattern for the 3D keys can be changed using the rotary 2, 3, 4 and 5 controls. They can be stored in
the memory for each pattern.
≥ With the sphere group (numbers 6001, 6301 to 6438)
R2: [Rotate] (rotation) setting
R4: [Time] setting
R5: [TransF] (transformation) setting
≥ With the flag group (numbers 6002, 6101 to 6139)
R2: [Width] (flag width) setting
R3: [Angle] setting
R4: [Time] (fluttering time) setting
R5: [Amp] (amplitude) setting
≥ With the accordion group (numbers 6003, 6201 to
6239)
R2: [Width] (accordion width) setting
R3: [Angle] setting
R5: [Amp] (amplitude) setting
≥ With perspectives (numbers 6006 and 6007, 6601 to
6634 and 6501 to 6532)
With door number 6004 to 6005, 6701 to 6716 groups
R2: [Rotate] (rotation) setting
R3: [Axis] (rotary axis) setting
R4: [View] (viewer) setting
R5: [Depth] setting
6007 to 6007: All parameters can be set.
6601 to 6634: Only [View] and [Depth] can be set.
6501 to 6532: Only [View] and [Depth] can be set.
Door
6004 to 6005: Only [Depth] can be set.
6701 to 6716: Only [View] and [Depth] can be set.
R1 R2 R3 R4 R5
R1 R2 R3 R4 R5
R1 R2 R3 R4 R5
R1 R2 R3 R4 R5
