Specifications
[GENERAL]
Power Source : 120 V AC, 50/60 Hz
Power Consumption : 52 W (with no optional accessories installed),
70 W (with all optional accessories installed)
Operating temperature: 41 °F to 104 °F (+ 5 °C to + 40 °C)
Operating humidity: Less than 80% (relative humidity)
Dimensions (W
k
H
k
D): 16-3/4
k
7-3/4
k
15-3/4 inch (424
k
197
k
400 mm)
Weight: 8.2 kg (with no optional accessories installed)
8.7 kg (with all optional accessories installed)
indicates safety information.
[VIDEO]
Video format: 525 (NTSC)/625 (PAL) switchable
Quantization: Main input: 9 bit
External input (EXT): 8 bit
Internal processing: 4: 2: 2: 4
8 bits (ON/OFF switching for Dynamic Rounding processing
enabled)
Key: 13.5 MHz
Y: 13.5 MHz
Pb/Pr: 6.75 MHz
S/N ratio: Component signal, Y: Less than –54 dB
Pb/Pr: Less than –52 dB
Composite signal, Y/C: Less than –50 dB
Band width: Main input Y: 0.5 MHz to 4.5 MHz (n1.0 dB)
Pb/Pr:0.2 MHz to 2.0 MHz
(+0.5 dB to –3.0 dB)
External input (EXT) Y: 0.5 MHz to 4.5 MHz (n1.0 dB)
Pb/Pr:0.2 MHz to 2.0 MHz (n1.0 dB)
K factor: Less than 1%
DG/DP: Less than 4%/2°
[AUDIO]
Sampling frequency: 48 kHz
Quantization: Analog Input: 20bit, Digital Input (option): 24bit
Frequency response: 20 Hz to 20 kHz (–1.0 dB to +1.0 dB)
Dynamic range: More than 85dB (analog In/out)
THD: Less than 0.05% (1 kHz)
Cross talk: Less than –70 dB (1 kHz, between any two channels)
Headroom: 20 dB/18 dB switchable
