Panasonic AG-MX70 - [VIDEO INPUT;OUTPUT]; [AUDIO INPUT;OUTPUT]

98
[OTHER]
Editor: D-sub 9-pin, RS-422A/232C switchable
RS-422A protocol; GVG/Sony switchable
Connectable Editor: Panasonic: AG-A850, AJ-A900,
SONY: BVE-2000, BVE-910, PVE-500
Tally Out: D-sub 9-pin, open-collector
k
8 ch
Collector current: Less than 50 mA,
Maximum voltage: 35 V DC
GPI: BNC
k
1, Make-contact
USB: Type-B connector
k
1, USB Ver.1.1 (cable length: max. 3 m)
Specifications
[VIDEO INPUT/OUTPUT]
Analog component input/output connectors: BNC a 4 (sources 1/2/3/4)
Y: 1.0 Vp-p, 75 h
Pb/Pr (525): 0.525/0.757 Vp-p switchable, 75 h
Pb/Pr (625): 0.7 Vp-p, 75 h
Analog composite input/output connectors: BNC a 8 (sources 1 to 8), 1.0 Vp-p, 75 h
YC input/output connectors: Mini-DIN4 a 4 (sources 1/2/3/4)
Y: 1.0 VP-P, 75 h
C: 0.286 VP-P, 75 h (525)/0.3 VP-P, 75 h (625)
EXT (external input) connector: BNC a 1 (Y/Pb/Pr), Analog component signals
Y: 1.0 Vp-p, 75 h
Pb/Pr (525): 0.757 Vp-p, 75 h
Pb/Pr (625): 0.7 Vp-p, 75 h
Key: BNC a 1, 1.0 Vp-p, 75 h
Analog composite signals (genlock possible)
G/L input connector: BNC a 1 (with loop-through configuration), 1.0 Vp-p, 75 h
Composite signal (genlock selection enabled from G/L, EXT-Key)
Preview output connector: BNC a 1, 1.0 Vp-p, 75 h
Advanced reference input connector: BNC a 1 (with loop-through configuration), 75 h,
composite signals
Sync: 0.286 Vp-p (525)/0.3 VP-P (625)
Burst: 0.286 Vp-p (525)/0.3 Vp-p (625)
[AUDIO INPUT/OUTPUT]
Analog audio (L/R) connectors: XLR a 4 sets, +4/0/–3 dBu switchable, 10 kh, balanced
AUX input (L/R) connectors: RCA a 2 sets, –10 dBV, 10 kh, unbalanced (AUX2 switchable
with MIC)
Audio output (L/R) connectors: Program 1: XLR a 1 set, +4/0/–3 dBu switchable, 47 h,
balanced
Program 2: RCA a 1 set, 10 dBv, 47 h, unbalanced
Mic input jack: M6 a 1, –60 dBv, 2 kh, unbalanced (switchable with AUX2)
Headphone output jack: M6 a 1, 8 kh, unbalanced
