Ref.No. PartNo. PartName&Description
Remarks Ref.No. PartNo. PartName&Description
Remarks
E2 VEP20781D SUB1P.C.BOARD 1FORAJ‑VF15BE
1 VYK9294 TOPCASEASS'Y 1
E2 VEP20781A SUB1P.C.BOARD 1FORAJ‑VF20BWP
2 VYK9295 BOTTOMCASEASS'Y 1
E2 VEP20781C SUB1P.C.BOARD 1FORAJ‑VF20BWE
3 VYC0884 MICHOLDERASS'Y 1
E3 VEP20782B SUB2P.C.BOARD 1FORAJ‑VF15BP/E
4 VMC1513 PLATESPRING(A) 1
E3 VEP20782A SUB2P.C.BOARD 1FORAJ‑VF20BWP/E
5 VKH0389 GUARDBAR 1
E4 VEP20783 LEDP.C.BOARD 1
6 VMG1217 CASEPACKING(1) 1
7 VMG1218 CASEPACKING(2) 1
8 VGU8170 TALLYKNOB 1
9 VGQ5321 TALLYBASE 1
10 VGL0837 BACKTALLYCOVER 1
11 VMG1219 BACKTALLYSHEET 1
12 VEC0969 VFCABLE 1
13 VEE0J46 13PCABLE 1
14 VEE0J45 10PCABLE 1
15 VMG1225 SWPACKING 1
16 VMZ2914 INSULATOR 1
17 VHD1264 VRNUT 3
18 VGU8171 VRKNOB 3
19 VEK8805 CRT/DYCONNECTORASS'Y 1FORAJ‑VR15BP
19 VEK8998 CRT/DYCONNECTORASS'Y 1FORAJ‑VF15BE
19 VEK8804 CRT/DYCONNECTORASS'Y 1FORAJ‑VF20WBP
19 VEK9001 CRT/DYCONNECTORASS'Y 1FORAJ‑VF20WBE
20 VGH4342 DISPLAYPLATE 1
21 VMZ2915 MASKSHEET 1
22 VEE0J44 10PCABLE 1CN4(MAIN)‑CN41(LED)
23 VMX2921 MASKSPACER 1FORAJ‑VR15BP/E
23 VMX2890 MASKSPACER 1FORAJ‑VF20WBP/E
24 VMG1221 LENSLOCKPACKING 1
25 VMX3242 SLIPRING 1
26 VGP5040 OUTSIDEHOLDER 1
27 VYC0809 LENSCASE 1FORAJ‑VR15BP/E
27 VYC0810 LENSCASE 1FORAJ‑VF20WBP/E
28 VMG1423‑S EYECAP 1
29 VFC3995 VFRAILASS'Y 1
30 VGM1655 LOCKTABLE 1
31 XSB3+8VZ SCREW 5
32 XWA3BFZ WASHER 3
33 VMP7716 STOPPERBASE 1
34 VMB3791 STOPPERSPRING 1
35 VMS7411 STOPPERPIN 1
36 VDL0965 UVFILTER 1
37 VDL0963 VFMIRROR 1
38 VMP6010 MIRRORGUIDE 1
39 VMP6011 MIRRORPLATE 1
40 VMG1449 MIRRORCUSHION 1
41 VMC1514 LOCKSPRING 1
42 VGQ1522 LOCKRING 1
43 VMX2887 LOCKSPACER 1
50 XSB4+12FXKS SCREW 2
51 VHD1528 SCREW 1
52 XWGV35D8G WASHER 1
54 VMX2885 SCREWWASHER 3
55 XVE26+A8FZ SCREW 5
56 MH‑04J8 SCREW 2
57 XQN2+A4FN SCREW 2
58 XXEV2W3FP HEXSCREW 3
59 XSB2+4FC SCREW 4
60 XQN2+A3FZ SCREW 2
61 XUC15FP E‑RING 1
62 XTN2+6CFN SCREW 1
63 MH04‑97 SCREW 4
64 XTN26+8CFZ SCREW 2
65 MH04‑92 SCREW 4
E1 VEP20780B MAINP.C.BOARD 1FORAJ‑VF15BP
E1 VEP20780D MAINP.C.BOARD 1FORAJ‑VF15BE
E1 VEP20780A MAINP.C.BOARD 1FORAJ‑VF20BWP
E1 VEP20780C MAINP.C.BOARD 1FORAJ‑VF20BWE
E2 VEP20781B SUB1P.C.BOARD 1FORAJ‑VF15BP
PRT‑2
MECHANICAL PARTS ASSEMBLY
