Panasonic AV-HS04M3 - Table of Contents; Introduction; Accessory

5 (E)
Contents
Safety precautions ......................... 1
Introduction ..................................... 5
Accessory ....................................... 5
Precautions for use ........................ 6
Name of each part .......................... 7
Mounting ......................................... 8
Connections .................................. 11
Appearance ................................... 12
Specifications ............................... 13
Introduction
When this board is installed in the AV-HS400N/E multi format line switcher, it enables two
DVI-I input lines to be supported.
Each of the two DVI-I input lines supports XGA, SXGA and WXGA (60 Hz) signals.
Accessory
Operating instructions .................. 1
