Panasonic AV-HS04M3 - Name of each Part

7 (E)
Name of each part
DVI-I DVI-I
DVI INPUTS


DVI-I input connectors [DVI INPUTS]
When connected to the SLOT1 option input connector: INPUT5
When connected to the SLOT2 option input connector: INPUT7

DVI-I input connectors [DVI INPUTS]
When connected to the SLOT1 option input connector: INPUT6
When connected to the SLOT2 option input connector: INPUT8

Setting switches
1 2 3 4 5 6 7 8
O N
1
2
3
4
O
N
SW1
SW500
<Setting switch table>
SW1
Switch no. Off On Factory setting
1 Reserved — — Off
2 Reserved — — Off
3 Reserved — — Off
4 Reserved — — Off
Use switches no. 1 to 4 at the “off” (factory setting) position.
SW500
Switch no. Off On Factory setting
1 Reserved — — Off
2 Reserved — — Off
3 Reserved — — Off
4 Reserved — — Off
5 Reserved — — Off
6 Reserved — — Off
7 Reserved — — Off
8 Reserved — — Off
Use switches no. 1 to 8 at the “off” (factory setting) position.
