Specifications
36
Appendix
Main Specifications
*1
Only a RAM card designed for PC2700 can be added.
*2
Use only a monaural condenser microphone.
*3
The Product Recovery DVD-ROM is required.
*4
The AC adaptor is compatible with power sources up to 240 V AC adaptor. This computer is supplied with a 125 V AC compatible AC cord.
*5
Approx. 0.9 W when the battery pack is fully charged (or not being charged) and the computer is OFF.
Approx. 1.5 W when the Wake up from LAN has been enabled.
*6
Rated power consumption.
Slots PC Card Slots Two Type I or Type II, or one Type III
Allowable current
(total for two slots)
3.3 V: 400 mA
5 V: 400 mA
RAM Module Slot
*1
200-pin, SO-DIMM, DDR SDRAM, PC2700 Compliant
Interface Parallel Port Dsub 25-pin female
External Display Port Mini Dsub 15-pin female
Serial Port Dsub 9-pin male
Microphone Jack
*2
Miniature jack, 3.5 DIA
Headphone Jack Miniature jack, 3.5 DIA
Impedance 32 Ω, Output Power 4 mW
× 2
External Keyboard/ Mouse Port Mini DIN 6-pin female
Expansion Bus Connector Dedicated 100-pin female
USB Port 4-pin x 2, USB 2.0
Modem RJ-11 Data: 56 kbps (V.92 & K56flex) FAX:14.4 kbps
LAN RJ-45 IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX,
IEEE 802.3ab 1000Base-T
Wireless LAN IEEE802.11a/b/g
IEEE1394 Interface Connector
4-pin
× 1
Pointing Device Touch Pad
Speaker Stereo Speaker
Sound WAVE and MIDI playback
Keyboard 87 keys
Operating System
Microsoft
®
Windows
®
XP Professional Service Pack 2 with
Advanced Security Technologies
Utility Programs Setup Utility, DMI Viewer, Adobe Reader, Hard Disk Data
Erase Utility
*3
, PC Information Viewer, Icon Enlarger, Loupe
Utility, WinDVD™ 5 (OEM Version), B’s Recorder GOLD7
BASIC, B’s CLiP 5, Intel
®
PROSet, Hotkey Settings
AC Adaptor
*4
Input 100 V - 240 V AC, 50 Hz/60 Hz
Output 15.6 V DC, 5.0 A
Power Consumption
*5
Approx. 35 W
*6
/ Approx. 90 W (maximum when recharging
in the ON state)
Environ-
ment
Operation Temperature 5 °C to 35 °C {41 °F to 95 °F}
Humidity 30% to 80% RH (No condensation)
Storage Temperature -20 °C to 60 °C {-4 °F to 140 °F}
Humidity 30% to 90% RH (No condensation)
Physical Dimensions (W × H × D) 325 mm × 47 mm × 278 mm {12.8 ’’ × 1.9 ’’ × 10.9 ’’}
Weight with the DVD-ROM & CD-R/RW drive
inserted in the multimedia pocket
Approx. 3.0 kg {Approx. 6.7 lb.}
with no devices inserted in the multi-
media pocket
Approx. 2.8 kg {Approx. 6.2 lb.}
