Handling and Maintenance
Useful Information
5. Remove the screws (19), except the one circled in the illustration, and
remove the cover.
6. Remove the tape that secures the cords, and move the built-in battery as shown in
the illustration. (Illustration: models without Smart Card slot)
7. Disconnect the connector, and remove the built-in battery. (Illustration: models
without Smart Card slot)
Cover
Tape
Built-in battery
Built-in battery
Connector
