Appendix
Battery Pack
RAM Module Slot
( “RAM Module”)
( “Battery Power”)
Use only a monaural condenser microphone (miniature jack).
Using an input source other than a monaural condenser mi-
crophone may not allow audio to be input or may damage
the equipment.
Microphone Jack
Use this jack to connect headphones or amplifier-equipped
speakers. Audio output from the internal speaker is disabled
when headphones or external speakers are connected.
Headphone Jack
Do not block or place the computer in a
location that may prevent proper venti-
lation.
CAUTION
( “USB Devices”)
( “External Display”)
USB Ports
DC-IN Jack
DC IN 16V
External Display Port
( “Wireless LAN”)
Wireless LAN Antenna
DVD-ROM & CD-R/RW Drive
( “DVD-ROM & CD-
R/RW Drive”)
Open Lever
Emergency Hole
( “DVD-ROM & CD-R/RW Drive”)
This hole allows heat to exit.
Ventilation Hole
Latch
Latch
A lithium ion battery that is recyclable powers the product you have purchased.
Please call 1-800-8-BATTERY for information on how to recycle this battery.
L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-
ion. Pour des renseignements sur le recyclage de la batterie, veuillez composer
le 1-800-8-BATTERY.
Names and Functions of Parts
(This latch is locked automatically)
