Panasonic CQ-DT6930ZE

12 TAPE PLAYER PARTS
12.1. IC´s and Transistors
DOLBY BLOCK [E8220A]
Ref.
No.
Part No. Part Name & Description Remarks
IC1 YEAMCX1980QK IC
Q401 YEANC114YKT Transistor
12.2. Diodes
REEL BLOCK [E8234]
Ref.
No.
Part No. Part Name & Description Remarks
TE1 YEADRPI221 Diode
12.3. Capacitors
DOLBY BLOCK [E8220A]
Ref.
No.
Part No. Part Name & Description Remarks
C201,
202
YECUS1H221JM Ceramic, 220PF 50WV
C203 ECEA1AKS330I Electrolytic, 33µF 10WV
C204 YECUS1H103KX Ceramic, 0.01µF 50WV
C205 ECEA1HKSR22I Electrolytic, 0.22µF 50WV
C206 YECUS1C104KX Ceramic, 0.1µF 16WV
C301,
302
YECUS1H221JM Ceramic, 220PF 50WV
C303 ECEA1AKS330I Electrolytic, 33µF 10WV
C304 YECUS1H103KX Ceramic, 0.01µF 50WV
C305 ECA1HSAR22I Electrolytic, 0.22µF 50WV
C306 YECUS1C104KX Ceramic, 0.1µF 16WV
C401 ECA1CSA100I Electrolytic, 10µF 16WV
C402 ECEA1AKS330I Electrolytic, 33µF 10WV
C403 YECUV2A103KX Ceramic, 0.01µF 100WV
C404 YECUS1E333KX Ceramic, 0.033µF 25WV
C405 ECA1HSA010I Electrolytic, 1µF 50WV
C406 YECUS1H153KX Ceramic, 0.015µF 50WV
C407 ECEA1CKS100I Electrolytic, 10µF 16WV
C408 YECUV2A103KX Ceramic, 0.01µF 100WV
C409 YECUV2A153KX Ceramic, 0.015µF 100WV
C501 YECUV1E334ZF Ceramic, 0.33µF 25WV
REEL BLOCK [E8234]
Ref.
No.
Part No. Part Name & Description Remarks
C1 to 3 YECUS1H471JM Ceramic, 470PF 50WV
12.4. Resistors
DOLBY BLOCK [E8220A]
Ref.
No.
Part No. Part Name & Description Remarks
R401 ERJ6GEYJ223 Chip, 22k
Ω
ΩΩ
Ω
1/10W
R402 ERJ6GEYJ183 Chip, 18k
Ω
ΩΩ
Ω
1/10W
R403 ERJ6GEYJ473 Chip, 47k
Ω
ΩΩ
Ω
1/10W
R404 ERJ6GEYJ334 Chip, 330k
Ω
ΩΩ
Ω
1/10W
R405 ERJ6GEYJ102 Chip, 1k
Ω
ΩΩ
Ω
1/10W
R406 ERJ6GEYJ682 Chip, 6.8k
Ω
ΩΩ
Ω
1/10W
R407 ERJ8GEYJ473V Chip, 47k
Ω
ΩΩ
Ω
1/8W
R408 ERJ8GEYJ223V Chip, 22k
Ω
ΩΩ
Ω
1/8W
R409 ERJ8GEYJ682V Chip, 6.8k
Ω
ΩΩ
Ω
1/8W
R501 ERJ6GEYJ472 Chip, 4.7k
Ω
ΩΩ
Ω
1/10W
REEL BLOCK [E8234]
Ref.
No.
Part No. Part Name & Description Remarks
R1, ERJ8GEYJ683V Chip, 68k
Ω
ΩΩ
Ω
1/8W
R3 ERJ6GEYJ472 Chip, 4.7k
Ω
ΩΩ
Ω
1/10W
R4 to 6 ERJ8GEYJ472V Chip, 4.7k
Ω
ΩΩ
Ω
1/8W
R7, 8 ERJ8GEYJ821V Chip, 820
Ω
ΩΩ
Ω
1/8W
12.5. Connectors
DOLBY BLOCK [E8220A]
Ref.
No.
Part No. Part Name & Description Remarks
CN1 YEAE012385 Connector, 17P
CN3 YEAESLW05R1 Connector, 5P
REEL BLOCK [E8234]
Ref.
No.
Part No. Part Name & Description Remarks
CN2 YEAE0110TKCR Connector, 10P
JP3 YEAJ071172 CORD W/Connector
12.6. Electric Parts
SWITCHES
Ref.
No.
Part No. Part Name & Description Remarks
SW1 YEAS09277 Switch
SW2 YEAS07174 Switch
SW3 YEAS08042 Switch
SW4 YEAS09277 Switch
SW5 EVQWJE001 Push Switch
VARIABLE RESISTORS
Ref.
No.
Part No. Part Name & Description Remarks
VR201,
301
EVNDXAA00B13 Variable Resistor
12.7. Mechanical Parts
MISCELLANEOUS
Ref.
No.
Part No. Part Name & Description Remarks
1 YEFA011640A Main Chassis Ass´y
2 YEFA011551A Head Chassis Ass´y
3 YEP9FZ2764 Head Ass´y
4 YEFR03083 Belt
5 YEFW05353 Shaft Collar
6 YEFX218286 Pinch Roller Ass´y(F)
7 YEFX218287 Pinch Roller Ass´y(R)
8 YEFX003748A Drive Gear(2)
9 YEFX239424A Cassette Guid Plate
10 YEFX0461685E Cassette Holder Ass´y(U)
11 YEFX003749 Drive Gear(3)
12 YEFX0461688A Lever
13 YEFX003750 Drive Gear(4)
14 YEFX0052021A Lever Spring
15 YEFX209268A Reel Ass´y(F)
16 YEFX0052016 Spring
17 YEFX0052018 Idler Plate Spring(1)
18 YEFX0052019 Idler Plate Spring(2)
19 YEFX0461687D Cassette Holder(L)
20 YEFX0052020 Pinch Roller Spring
21 YEFX0052022 Spring
22 YEFX0052043A Lock Plate Spring
23 YEFX0052023B Lack Plate Spring
24 YEFX003752E Lack Plate
25 YEFX209269A Reel Ass´y(R)
26 YEFX234182 Cam(F)
27 YEFX003754 Gear
28 YEFX234183 Cam(R)
29 YEFX003755 Change Gear
30 YEFX003744A Idler Gear Ass´y(F)
31 YEFX003746A Idler Gear Ass´y(R)
32 YEFX030097 Worm Gear Stopper
33 YEFX003753B Play Idler Gear
34 YEFX0052015 Back Tension Spring
35 YEP0FX2565 Main Motor Ass´y
36 YEP0FX2566A Drive Chassis Ass´y
37 YEFX213209A Flywheel
38 YEP0FX9027S Loading Motor Ass´y
39 YEP0PT8220A0 PCB w/Component
40 XUC15V Retaining Ring, 1.5mm
15
CQ-DT6930ZE
