Panasonic CQ-JT1010X

12 CD PLAYER PARTS
MISCELLANEOUS
Ref.
No.
Part No. Part Name & Description Remarks
1 YGFA011781 Upper Chassis (4-A)
2 YGFX236153 Disk Guide (4-A)
3 YGFX0462017 Link Lever (4-A)
4 YGFX0462018 Detection Lever (2) (4-B)
5 YGFX0052357 Detection Lever (2) Spring (4-B)
6 YEJT03131 Tapping Screw, 2.6 mm* 5mm (2-C)
(2-B)
7 YGFX249461 Clamp Arm (3-A)
8 YGFX007640 Clamper (3-A)
9 YGFX0052363 Clamper Spring Plate (3-A)
10 YEFX999957 Ball Bearing (3-A)
11 YGFX0462013 Detection Lever (1) (3-A)
12 YGFX0052352 Detection Lever (1) Spring (3-A)
13 YGFA011795 Suspension Chassis Ass´y (3-A)
14 YEP0FX3100 Optical Pick-up Ass´y (3-B)
15 YEFW04150 Feed Screw Housing A (2-B)
16 YEFW04137A Feed Screw Housing B (2-B)
17 YGFX0052386 Thrust Adjusting Spring (2-B)
18 YEFX236144B Traverse Guide (3-A)
19 YGFX9992027 Feed Screw Carrier (3-B)
20 YEFX9991458A FPC Holder (2-A)
21 YGJT03240 Traverse Gear Ass´y (2-B)
22 YEJS02037 Screw, (Pick-up) (3-A)
(3-B)
23 XYN2+C5FX Screw, (FPC) 2mm * 5mm (2-A)
24 XYN2+J10FX Screw, (Housing) 2mm * 10m (2-B)
25 YEFX0051590 Spring Washer (3-A)
26 XUC15V Retaining Ring, 1.5mm (3-A)
27 YEFX9991806A Sealed Plate (3-B)
28 YGP0FX3503 Traverse Motor Ass´y (2-B)
29 YEAS23151A Inner Switch (2-B)
30 YEFR03080 Rubber Belt (2-B)
31 YEFX026124A Idler Pulley (2-B)
32 YGFX018611 Motor Bracket Ass´y (2-B)
33 YEJS02018FZ Screw, (SW) (2-B)
34 XQN2+A25FX Screw, 2mm * 25mm (2-B)
35 YGP0FX3529 Spindle Motor Ass´y (2-A)
36 YEFX0051991C Spring (Motor) (2-A)
37 YGFX0052353 Clamper Spring (2-A)
38 YGAJ071286 Motor Cable (2-A)
39 XQN17+A25FX Screw, 1.7mm * 25mm (3-A)
40 YGFX0462019 Feeder Arm Ass´y (1-A)
41 YGP0FX3507 Roller Gear Ass´y (2-B)
42 YEFW04144 Roller Shaft Collar (1) (2-A)
43 YEFW04138 Roller Shaft Collar (2) (2-A)
44 YEFX218282 Rubber Roller (2-A)
45 YEJW04128 Washer (2-A)
46 YGFX0052362 Spring (Feeder Arm) (1-A)
47 YGFX0462015 Suspension Lock Plate (L) (1-A)
48 YGP0FX3504 Suspension Lock Plate (R)
Ass´y
(1-B)
49 YGFX0052355 Spring (Rack Gear) (1-A)
50 YGFX0052356 Spring (Rack Lock Lever) (1-B)
51 YGFX0052360 Spring (Suspension Lock Plate
L)
(1-A)
52 YGFX0052361 Spring (Lock Plate) (3-C)
53 YGFA011779 Bottom Chassis Ass´y (3-C)
54 YGFX003940 Driving Gear (1) (3-C)
55 YGFX003941 Driving Gear (2) (3-C)
56 YGP0FX3506 Loding Motor Ass´y (3-C)
57 YGFX018605 Loding Motor Bracket Ass´y (3-C)
58 XQN2+A25FX Screw, (Motor) 2mm * 25mm (3-C)
59 YEJS06188 Screw (2-C)
60 YEFS04693 Oil Dumper (1-C)
61 YGFX0052358 Suspension Spring (A) (2-C)
62 YGFX0052359 Suspension Spring (B) (2-C)
20
CQ-JT1010X / CQ-JS6910X
