33
R796 D0GD222JA017 Chip, 2.2kΩ 1/8W T
R797 D0GDR00JA017 Chip, 0Ω 1/8W T
R798 D0GB103JA008 Chip, 10kΩ 1/10W T
R799 D0GDR00JA017 Chip, 0Ω 1/8W T
NETWORK RESISTORs
RA601 D1H81044A043 Chip Network Resistor T
RA602 D1H81014A043 Chip Network Resistor T
RA603 D1H81024A043 Chip Network Resistor T
RA604 D1H81024A043 Chip Network Resistor T
RA606 D1H81024A043 Chip Network Resistor T
RA607 D1H81024A043 Chip Network Resistor T
RA609 D1H81024A043 Chip Network Resistor T
RA610 D1H81024A043 Chip Network Resistor T
RA612 D1H81024A043 Chip Network Resistor T
RA613 D1H81024A043 Chip Network Resistor T
CRYSTALs
X601 H0J419400014 Crystal T
X602 H0J720400012 Crystal T
NOISE FILTER
Z51 J0LM00000001 Noise Filter T
COILs
FB601 J0JGC0000020 Coil T
L51 G1C150JA0036 Chip RF Coil T
L52 G1CR56JA0036 Coil T
L53 G1C100JA0036 RF Coil T
L55 G1C101JA0036 RF Coli T
L151 G1C220K00023 Chip RF Coil T
L152 G1C220K00023 Chip RF Coil T
L201 J0JGC0000029 Coil T
L202 J0JGC0000029 Coil T
L203 J0JGC0000029 Coil T
L281 G1C220JA0036 Coil T
L301 J0JGC0000029 Coil T
L302 J0JGC0000029 Coil T
L303 J0JGC0000029 Coil T
L601 G1C220JA0036 Coil T
L701 G0A151J00006 RF Coil T
L702 G1C220ZA0087 RF Coli T
L703 G1C470ZA0087 RF Coli T
L704 G1C470ZA0087 RF Coli T
L780 G1C2R2JA0036 RF Coli T
CONNECTORs
CN160 K1KA20B00042 20P Connector T
CN252 K1MN40BA0112 40P Connector T
CN256 K1KA03A00063 3P Connector T
CN601 K1KB08AA0201 8P Connector T
CN701 K1FA116B0028 16P Connector T
CN707 K1MN20BA0111 20P Connector T
CN708 K1MN40AA0030 40P Connector T
ANTENNA
ANT51 K1KB02A00079 ANT T
[E9939A]TFT Block
IC's AND TRANSISTORs
IC401 IR3M58M IC T
IC402 AP2202K25TRE IC T
IC451 C0DBAZA00017 IC T
IC452 C0FBBD000065 IC T
IC801 T100A IC T
Ref. No. Part No. Part Name & Description Remarks
IC802 C3EBCC000065 IC T
IC901 C0ABBB000069 IC T
Q401 B1GBNCEJ0001 Transistor T
Q402 B1GBCFJJ0007 Transistor T
Q403 B1CHMC000009 Transistor T
Q404 B1CHMC000009 Transistor T
Q405 B1CHMC000009 Transistor T
Q451 P2503NVG Transistor T
Q452 P2503NVG Transistor T
Q501 B1GBCFJJ0007 Transistor T
Q502 B1GBCFJJ0007 Transistor T
Q805 B1ABCF000021 Transistor T
Q806 B1ABCF000021 Transistor T
Q807 B1ABCF000021 Transistor T
Q808 B1ABCF000021 Transistor T
Q809 B1ABCF000021 Transistor T
Q810 B1ABCF000021 Transistor T
DIODEs
D401 B0JCGD000002 Diode T
D402 B0JCGD000002 Diode T
D403 B0JCGD000002 Diode T
D451 B0ADCJ000014 Diode T
D452 B0BC5R600010 Zener Diode T
D453 B0BC5R600010 Zener Diode T
D454 B0ADCJ000014 Diode T
D501 B3ABB0000284 LED T
D502 B3ABB0000284 LED T
D503 B3ABB0000284 LED T
D803 B0BC3R700004 Zener Diode T
D804 B0BC3R700004 Zener Diode T
D805 B0BC3R700004 Zener Diode T
D901 B0JDAE000004 Diode T
D902 B0BD6R800002 Diode T
D903 B0BD6R800002 Diode T
D911 B0BC5R600010 Zener Diode T
D912 B0BC5R600010 Zener Diode T
D913 B0BC5R600010 Zener Diode T
CAPACITORs
C401 F1H1H104A783 Ceramic, 0.1µF 50WV T
C402 F1H1H102A842 Chip, 1000PF 50WV T
C403 F1H1H472A842 Chip, 4700PF 50WV T
C404 F1H1H4710003 Ceramic, 470PF 50WV T
C405 F1H0J1050010 Chip, 1µF 6.3WV T
C406 F1H1H104A783 Ceramic, 0.1µF 50WV T
C407 F1J1A106A023 Chip, 10µF 10WV T
C408 F1J1A106A023 Chip, 10µF 10WV T
C409 F1K1C225A069 Chip, 2.2µF 16WV T
C410 F1H1H104A783 Ceramic, 0.1µF 50WV T
C411 F1J1A106A023 Chip, 10µF 10WV T
C412 F1K1C225A069 Chip, 2.2µF 16WV T
C413 F1H1H104A783 Ceramic, 0.1µF 50WV T
C414 F1H1H104A783 Ceramic, 0.1µF 50WV T
C415 F1H1H104A783 Ceramic, 0.1µF 50WV T
C416 F1H0J1050010 Chip, 1µF 6.3WV T
C417 F1J1A106A023 Chip, 10µF 10WV T
C418 F1J1A106A023 Chip, 10µF 10WV T
C419 F1H0J1050010 Chip, 1µF 6.3WV T
C420 F1H1H104A783 Ceramic, 0.1µF 50WV T
C422 F1J1A106A023 Chip, 10µF 10WV T
C423 F1J1A106A023 Chip, 10µF 10WV T
C425 F1J1A106A023 Chip, 10µF 10WV T
C426 F1J1A106A023 Chip, 10µF 10WV T
C427 F1J1A106A023 Chip, 10µF 10WV T
C428 F1K1C1060001 Ceramic, 10µF 16WV T
C429 F1K1C1060001 Ceramic, 10µF 16WV T
C430 F1K1C1060001 Ceramic, 10µF 16WV T
C431 F1J1A106A023 Chip, 10µF 10WV T
C432 F1J1A106A023 Chip, 10µF 10WV T
C435 F1H1H100A840 Chip, 10PF 50WV T
C436 F1H1H100A840 Chip, 10PF 50WV T
Ref. No. Part No. Part Name & Description Remarks
