Panasonic CS-A12DKD - Replacement Parts List (Outdoor Unit)

18 Replacement Parts List (Outdoor Unit)
<Model: CU-A7DKD / CU-A9DKD>
REF.
NO.
PART NAME & DESCRIPTION QTY. CU-A7DKD CU-A9DKD REMARKS
1 CHASSY ASS’Y 1 CWD50K2112
←
2 SOUND PROOF MATERIAL 1 CWG302255 ←
3 FAN MOTOR BRACKET 1 CWD541075 ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551060 ←
5 FAN MOTOR 1 CWA951388 ← 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406 ←
7 PROPELLER FAN ASS’Y 1 CWH03K1020
←
8 NUT - PROPELLER FAN 1 CWH56053 ←
9 COMPRESSOR 1 2RS122D5BC02 2PS156D3BB02 0
10 ANTI - VIBRATION BUSHING 3 CWH50077 ← 0
11 NUT - COMPRESSOR MOUNT 3 CWH56000
←
12 CONDENSER 1 CWB32C1493 ←
13 4-WAY VALVE 1 CWB001012
←
14 STRAINER 1 CWB11025
←
15 HOLDER COUPLING 1 CWH351047 ←
16 2-WAY VALVE (LIQUID) 1 CWB021218 CWB021217 0
17 3-WAY VALVE (GAS) 1 CWB011258 CWB011257 0
18 FLARE NUT (1/4”) 1 CWT25078
←
19 FLARE NUT (3/8”) 1 CWT25005 ←
20 OVERLOAD PROTECTOR 1 CWA121050 CWA121091 0
21 HOLDER - O.L.P. 1 CWH7041200 ←
22 TERMINAL COVER 1 CWH171011
←
23 NUT - TERMINAL COVER 1 CWH7080300 ←
24 SOUND PROOF BOARD 1 CWH151074
←
25 CONTROL BOARD 1 - -
26 TERMINAL BOARD ASS’Y 1 CWA28K1021
←
0
27 CAPACITOR - COMPRESSOR 1 DS371206CPNA DS371306CPND 0
28 HOLDER CAPACITOR 1 CWH301038 CWH301035
29 CAPACITOR - FAN MOTOR 1 DS441205NPQA ← 0
30 CABINET SIDE PLATE (L) 1 CWE041110A ←
31 CABINET SIDE PLATE (R) 1 CWE04C1042 ←
32 CABINET FRONT PLATE 1 CWE06K1048 ←
33 WIRE NET 1 CWD041057A ←
34 CABINET TOP PLATE 1 CWE031041A
←
36 CONTROL BOARD COVER 1 CWH13C1099
←
37 L. TUBE 1 CWH5850080
←
38 TUBE ASSY (CHK VALVE, CAPILLARY) 1 CWT01C3216 -
39 CAPILLARY TUBE ASSY 1 - CWB15K1146
40 ELECTRO MAGNETIC SWITCH 1 CWA00059
←
41 ELECTROLYTIC CAPACITOR 1 CWA32C1003
←
42 TEMPERATURE RELAY 1 CWA14C1009
←
43 V-COIL COMPLETE 1 CWA43C2174
←
44 PACKING - L. TUBE 1 CWB81012
←
45 OPERATING INSTRUCTIONS 1 CWH564479 ←
46 INSTALLATION INSTRUCTIONS 1 CWF612620 ←
47 INSTALLATION INSTRUCTIONS 1 CWF612681
←
48 INSTALLATION INSTRUCTIONS 1 CWF612738 ←
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
77
CS-A7DKD CU-A7DKD / CS-A9DKD CU-A9DKD / CS-A12DKD CU-A12DKD /
