Panasonic CS-A18BTP

H.C. = Heating Capacity
IPT = Power Consumption
15 CAPACITY AND POWER CONSUMPTION
15.1. HEATING PERFORMANCE
Model Heating capacities are based on conditions below.
CS-A18BTP
Heating capacity
5.0 kW
1 phase, 50Hz, 220V
Indoor temperature 20°C D.B.
Outdoor temperature 7°CD.B.6°CW.B.
Standard air volume 14m
3
/min
Inlet Air Outdoor Temperature (°C W.B.)
External Static Pressure
(Pa) Air Volume (m
3
/min)
Entering Air Dry
Bulb (°C)
-6°C 0°C 6°C 12°C
H.C. IPT H.C. IPT H.C. IPT H.C. IPT
15 4.09 1.32 4.90 1.50 5.88 1.79 6.83 2.11
14 20 3.86 1.39 4.62 1.60 5.60 1.88 6.72 2.22
25 3.64 1.47 4.37 1.69 5.32 1.97 6.44 2.31
Inlet Air Outdoor Temperature (°C W.B.)
External Static Pressure
(Pa) Air Volume (m
3
/min)
Entering Air Dry
Bulb (°C)
-6 6 -6 6
H.C. IPT H.C. IPT H.C. IPT H.C. IPT
15 4.09 1.33 4.90 1.52 5.88 1.81 6.83 2.13
14 20 3.86 1.41 4.62 1.62 5.60 1.90 6.72 2.24
25 3.64 1.48 4.37 1.71 5.32 2.00 6.44 2.34
35
