33 HEATING CAPACITY PERFORMANCE DATA
Model Power
Source
Inlet Air Outdoor Temperature (°CW.B.)
External Static Pressure (Pa) Entering Air -6 °C 0 °C 6 °C 12 °C
Air Volume (m
3
/min) Dry Bulb (°C) H.C. IPT H.C. IPT H.C. IPT H.C. IPT
CS- 230V, 15 4.09 1.32 4.90 1.50 5.88 1.79 6.83 2.11
A18BTP 50Hz, 14 20 3.86 1.39 4.62 1.60 5.60 1.88 6.72 2.22
Single phase 25 3.64 1.47 4.37 1.69 5.32 1.97 6.44 2.31
H.C. = Heating Capacity, IPT = Power Consumption
Model Heating capacities are based on conditions below.
CS-A18BTP 1 phase, 50Hz, 220V
Heating capacity Indoor temp. 27°C D.B. 19°CW.B.
5.0kW Outdoor temp. 35°C D.B.
Standard air volume 14 m
3
/min
110
