Panasonic CS-A24BB4P Service Manual

ITEM / MODEL
CS-A34BB4P, CU-A34BBP8
Condition by JIS B 8615
Volts V 380 400
415
Phase 3N 3N 3N
Power Consumption kW Cool 3.30 3.30
3.30
Heat 3.40 3.40
3.40
Running Current A Cool 5.70 5.70
5.70
Heat 5.80 5.80
5.80
Starting Current A 39 41 42
Power Factor % Cool 88 84 81
Heat 89 85 82
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V
50Hz
3.6. CS-A43BB4P / CU-A43BBP8
ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A43BB4P CU-
A43BBP8
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL51P (Wireless)
Cooling Capacity kW 12.5
BTU/h 42,700
Heating Capacity kW 14.0
BTU/h 47,800
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 30 Me 27 Lo 24 Hi 82
Medium and Low Speed cfm 1059 953 847 2895
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 1100
x
inch 11-7/16 x 33-1/24 x 33-1/24 48-7/24 x 35-7/16
x
Net Weight kg 33 114
lbs 73 251
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x
Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting Method - Direct on-line
starting
Motor Type - 2-pole 3-phase
induction
motor
Input kW - Cool/Heat
3.85
Rated
Output
kW - 3.5
19

Panasonic CS-A24BB4P Specifications
