3. SPECIFICATION (HEAT PUMP TYPE )
3.1. CS-A24BB4P / CU-A24BBP5
ITEM / MODEL
Indoor Unit Outdoor
Main Body CS-A24BB4P CU-
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL51P (Wireless)
Cooling Capacity kW 6.3
BTU/h 21,500
Heating Capacity kW 7.1
BTU/h 24,200
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 17 Me 15 Lo 14 Hi 43
Medium and Low Speed cfm 600 530 494 1518
Outside Dimension (H x W x D) mm 240 x 840 x 840 900 x 900
inch 9-7/16 x 33-1/24 x 33-1/24 35-7/1 6 x 35-7/16
Net Weight kg 26 81
lbs 57 179
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
10
