Panasonic CS-A24BB4P Service Manual

Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting Method - Direct on-line
starting
Motor Type - 2-pole single
phase
induction
motor
Input kW - Cool/Heat
2.31
Rated
Output
kW - 1.9
Fan Type, Number of Set Turbo fan-1 Propeller
fan
Motor Type 6-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.08 0.11
Rated
Output
kW 0.03 0.05
Air-heat Exchanger Slit-fin type Louvre-fin
type
Refrigerant Control Cool Capillary tube -
Heat - Capillary
tube
Refrigerant Oil (Charged) litre - MS32 (
1.3)
Refrigerant (Charged) kg
-
(2.5)
lbs (5.5)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
thermostat
fan motor, Crankcase heater, High and heating
pressure
switch, Current transformer
Noise Level Cool dB (A) Hi 42 Me 40 Lo 38 Hi 50
Heat Hi 42 Me 40 Lo 38 Hi 51
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B.
(68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F D.B.),
6°C W.B. (42.8°F W.B.)
