Panasonic CS-A24BB4P Service Manual

ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A34BB4P CU-
C34BBP8
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 10.0
BTU/h 34,100
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 26 Me 23 Lo 20 Hi 70
Medium and Low Speed cfm 918 812 706 2471
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 900
x
inch 11-7/16 x 33-1/24 x 33-1/24 48-1/24 x 35-7/
16
Net Weight kg 30 95
lbs 66 209
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x
Compressor
Type, Number of Set - Hermetic-1 (
Scroll),
Starting Method - Direct on-line
starting
Motor Type - 2-pole 3-phase
induction
motor
Input kW - Cool
2.93
Rated
Output
kW - 2.8
Fan Type, Number of Set Turbo fan-1 Propeller
fan
Motor Type 6-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.15 0.24
Rated
Output
kW 0.08 0.055 x
2
Air-heat Exchanger Slit-fin type Louvre-fin
type
Refrigerant Control Capillary tube -
Refrigerant Oil (Charged) litre -
SONTEX200LT
Refrigerant (Charged) kg
-
(4.2)
lbs (11.1)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
thermostat
fan motor, Crankcase heater, High pressure
switch,
Current transformer
Noise Level dB (A) Hi 45 Me 42 Lo 40 Hi 55
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.), and outdoor air
32
