10.2.5. CONNECT THE CABLE TO THE
INDOOR UNIT
1. The inside and outside indoor/outdoor connecting cable can
be connected without removing the front grille.
2. Indoor/outdoor connecting cable between indoor unit and
outdoor unit shall be approved polychorprene sheathed 5 ×
2.5 mm
2
flexible cord 245 IEC 57 ,type designation H05 RN-F
or heavier cord.
•
Secure the cable onto the control board with the holder
(clamper).
INSTALLATION OF AIR PURIFYING FILTERS
1. Open the front panel.
2. Remove the air filters.
3. Hold the catechin filters by their tabs and install as shown in
the illustration at below.
47
CS-A28BKP5/CU-A28BKP5
