18 Replacement Parts List
<Model: CU-A28BKP5>
•
“
■
” marked parts are recommended to be kept in stock.
•
“
●
” marked parts are supplied from TAMACO, Taiwan.
•
“
▲
” marked parts are supplied from MACC, Malaysia.
70
CS-A28BKP5/CU-A28BKP5
NO DESCRIPTION & NAME QTY CU-A28BKP5 REMARKS
1 CHASSIS ASS’Y 1 CWC5244-200A
●
2 SOUND PROOF 1 CWC5236-060
●
3 FAN MOTOR BRACKET 1 CWC5241-830
●
4 SCREW - (FAN MOTOR BRACKET) 6 XTT4D10CXW
●
5 PARTICULAR PLATE - LEFT (HOLD - FAN MOTOR) 1 CWC4934-850
●
6 PARTICULAR PLATE - RIGHT (HOLD - FAN MOTOR) 1 CWC4934-860
●
7 FAN MOTOR 1 CWC4301-380
■ ●
8 SCREW - FAN MOTOR 3 XTT4D10CXW
●
9 PROPELLER FAN ASS’Y 1 CWC5700-500
10 NUT - PROPELLER FAN 1 CWC4583-020
●
11 HOLDER - FOR F/MOTOR & LEAD WIRES 3 CWC4620-110
●
12 COMPRESSOR 1 CWC6815-280
■ ●
13 PACKING - COMP. MOUNT 3 CWC4604-010
●
14 NUT - COMP. MOUNT 3 CWC4521-130
●
15 CONDENSER 1 CWC6305-570
●
16 HOLDER - COUPLING ASS’Y 1 CWC5240-070A
●
17 3-WAYS VALVE (LIQUID) 1 CWC4034-150
■ ●
18 3-WAYS VALVE (GAS) 1 CWC4034-170
■●
19 4-WAYS VALVE ASS'Y 1 CWC4034-740
20 V-COIL COMPLETE 1 CWC4019-400
21 STRAINER 1 CWC4042-340
●
22 TUBE ASS'Y (CAPILLARY TUBE.CHECK VALVE) 1 CWC5932-090
●
23 CONTROL BOARD ASS’Y 1 CWC4712-690
●
24 CAPACITOR - FAN MOTOR 1 CWC4069-960
■ ●
25 CAPACITOR - COMPRESSOR 1 CWC4069-780
■ ●
26 HOLDER - CAPACITOR 1 CWC4828-750
●
27 TERMINAL BOARD ASS’Y 1 CWC4706-590
■ ●
29 SENSOR COMPLETE 1 CWC3900-240
30 HOLDER - SENSOR 1 CWC5040-130
●
31 HOLDER - SENSOR (FOR TUBE) 1 CWC5040-120
●
32 U METAL PIECE
35
ELECTRONIC CONTROLLER
1
CWC3919-670
36
WIRE NET (REAR)
1
CWC4537-530A
●
37 POLY-E FOAM 1 CWN5A30-325
38
CABINET TOP PLATE ASS’Y
1 CWC5030-520A
●
39 CONTROL BOARD COVER 1 CWC4936-960A
●
40 HANDLE 2 CWC4520-120
●
41 RAIN COVER 1 CWC4631-880
●
42 SCREW 1 XYN4+C8D
●
43 SCREW 20 CWC4585-520
●
44
POLY-E FOAM
4
CWE3A325-360
●
45 CABINET ASS’Y 1 CWC5030-940A
●
46 1
●
47 1
●
48
CABINET REAR PLATE COMPLETE
1 CWC5030-820
●
CWC5030-640
■ ●
●
●
●
(Note)
■●
■●
CABINET SIDE PLATE (LEFT)
CABINET FORNT PLATE ASS'Y
CWC5030-720A
28
33
34
1
1
CWC4825-120
1
CWC4627-100HOLDER-PS,CORD
MUFFLER
■ ●
■ ●
●
●
1
CWC6040-320
SCREW CWC4580-930
