Panasonic CS-A28BKP5 User Manual

19 Electronic Parts List
Note
Electronic Controller: C3919-420A (CS-A28BKP5)
SYMBOL DESCRIPTION & NAME PART NO.
IC1 INTEGRATED CIRCUIT C4083-910
IC2
INTEGRATED CIRCUIT C4083-450
IC3 INTEGRATED CIRCUIT C4083-860
IC4 INTEGRATED CIRCUIT C4083-730
IC5 INTEGRATED CIRCUIT C4083-720
PC1 PHOTO COUPLER C4094-040
Q1 TRANSISTOR C4086-060T
Q2 TRANSISTOR C4086-240T
Q3, Q5 TRANSISTOR J4086-080T
D1 ~ D4 DIODE E4060-020T
ZD1 ZENER DIODE C4082-100T
ZNR1, ZNR2, ZNR3 ZNR C4084-150
RY-HOT RELAY ELECTRO MAGNETIC C4104-180
RY-HI, ME, LO RELAY ELECTRO MAGNETIC C4104-170
RY-COMP RELAY ELECTRO MAGNETIC C4076-310
SSR1 SSR C4092-070
SW1, SW2 PUSH SWITCH C4001-200
FUSE FUSE XBA2C31TR0
X1 RESONATOR F4090-010T
BZ BUZZER (SOUND GENERATOR) C4091-030
•
All parts are supplied from TAMACO, Taiwan.
Electronic Controller: CWC3919-670 (CU-A28BKP5)
SYMBOL DESCRIPTION & NAME PART NO.
IC1 INTEGRATED CIRCUIT C4083-950A
IC2 INTEGRATED CIRCUIT C4083-720
IC3 INTEGRATED CIRCUIT C4083-730
IC4 INTEGRATED CIRCUIT C4083-450
Q1 TRANSISTOR C4086-060T
Q2 TRANSISTOR C4086-240T
D1 ~ D12 DIODE E4060-240T
ZD1
ZENER DIODE
C4082-100T
ZNR1 ~ ZNR3 ZNR C4084-150
T1, T2
TRANSFORMER
C4017-780
CR1 SURGE ABSORBER
C4085-560
RY-HOT
RELAY
C4104-170
RY-DEICE
RELAY
C4107-170
RY-OFF
RELAY
C4107-170
RY-H/L
RELAY
C4107-170
FUSE
FUSE XBA2C31TR0
X1
RESONATOR
A45ST4.0MGWT
•
All parts are supplied from TAMACO, Taiwan.
Q6~ Q8
C4086-250T
TRANSISTOR
71
CS-A28BKP5/CU-A28BKP5
Note

Panasonic CS-A28BKP5 Specifications

General

Brand	Panasonic
Model	CS-A28BKP5
Category	Air Conditioner
Language	English
