Panasonic CS-A9DKD

Unit Indoor Unit Outdoor Unit
Fan Motor Description Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 60.5 - 66.0 71.5 - 80.3
Rated Output W 15 31
Fan Speed Low rpm Cooling; 900 - 900
Heating; 960 - 960
—
Medium rpm Cooling; 1,120 - 1,120
Heating; 1,120 - 1,120
—
High rpm Cooling; 1,280 - 1,280
Heating;1,310 - 1,310
845 - 860
SuperHigh rpm Cooling; 1,310 - 1,310
Heating; —
—
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×24
FPI 21 16
Size (W × H × L) mm 610 × 315 × 25.4 720 × 504 × 36.38
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — ATMOS M0 OR SUNISO 4GDID
Refrigerant (R-22) g (oz) — 1,080 (38.1)
Thermostat — —
Protection Device — —
Capillary Tube Length mm — Cooling; 630, Heating; 455
Flow Rate l/min — Cooling; 6.5, Heating; 13.6
Inner Diameter mm — Cooling; 1.2 Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 35 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 440VAC 2.0 µF, 440VAC
Note:
• Specifications are subjected to change without prior notice for further improvement.
11
