3 Product Specifications
3.1. CS-C18DKV CU-C18DKV
Unit CS-C18DKV CU-C18DKV
Power Source (Phase, Voltage, Cycle) ,V,Hz Single, 220, 60
Cooling Capacity kW (BTU/h) 5.30 (18,100)
Moisture Removal l/h (Pint/h) 2.9 (6.1)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Lo m
3
/min (cfm) 12.5 (440) —
Me m
3
/min (cfm) 13.6 (480) —
Hi m
3
/min (cfm) 14.8 (520) 51.0 (1,800)
SHi m
3
/min (cfm) 15.4 (545) —
Noise Level dB (A) High 42, Low 37 High 54
Electrical Data Input Power kW 1.72
Running Current A 8.0
EER W/W (BTU/hW) 3.08 (10.52)
Starting Current A 47.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 3-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 29 - 17/32 (750)
Width inch (mm) 39 - 9/32 (998) 34 - 7/16 (875)
Depth inch (mm) 9 - 1/16 (230) 13 - 19/32 (345)
Net Weight lb (kg) 24 (11.0) 105 (47.5)
Compressor Description — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 1.2
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (6-poles)
Input W 40.0 162.8
Rated Output W 30 69
Fan Speed Low rpm 1,150 —
Medium rpm 1,250 —
High rpm 1,360 870
SuperHigh rpm 1,420 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Gold Coat)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×34
FPI 21 16
Size (W × H × L) mm 810 × 315 × 25.4 850.5
870.5
× 714.0 × 25.4
Refrigerant Control Device — Capillary Tube
6
CS-C18DKV CU-C18DKV / CS-C24DKV CU-C24DKV
