2.2. CS-C24HKD CU-C24HKD
1. Cooling capacities are based on indoor temperature of 27qC D.B. (80.6qF D.B.), 19.0qC W.B. (66.2qF W.B.) and outdoor air
temperature of 35qC D.B. (95qF D.B.), 24qC W.B. (75.2qF W.B.)
Item Unit Indoor unit Outdoor unit
Performance Test Condition NEW JIS
Capacity
kW 7.03 - 7.03
BTU/h 24000 - 24000
*kJ/h —
EER
W/W 2.99 - 2.92
BTU/hW 10.21 - 9.96
Noise Level
dB (A) High: 46 Low: 40 High: 53 / 54
Power level dB — —
Moisture Removal
l/h 4.0
(pt/h) 8.5
Air Volume
Lo
m
3
/m (ft
3
/m)
14.0 (496) - 14.0 (496) —
Me
m
3
/m (ft
3
/m)
15.7 (556) - 15.7 (556) —
Hi
m
3
/m (ft
3
/m)
16.9 (600) - 16.9 (600) 45.5 (1610) - 46.5 (1640)
SHi
m
3
/m (ft
3
/m)
17.9 (636) - 17.9 (636) —
Refrigerant Control Device — Capillary Tube
Refrigerant Oil (Charged)
cm
3
—
ATMOS M60 or
SUNISO 4GDID (700cm
3
)
Refrigerant (Charged) R22 kg (oz) — 1.39 (49.1)
Dimension
Height mm (inch) 275 (10 - 27/32) 750 (29 - 17/32)
Width mm (inch) 998 (39 - 5/16) 875 (34 - 15/32)
Depth mm (inch) 230 (9 - 1/16) 345 (13 - 19/32)
Net Weight kg (lbs) 11 (24) 58 (128)
Pipe Diameter
Gas mm (inch) 15.88 (5/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 20 (65.6)
Pipe Length Range m (ft) 3 (9.8) - 25 (82.0)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner diameter mm 16 —
Length mm 650 —
Compressor
Type — Hermetic motor
Motor Type — Induction (2-poles)
Rated Output W — 2.2k
Fan
Type Cross-flow Fan Propeller Fan
Material ASHT-18 PP Resin
Motor Type Transitor (8-poles) Induction (6-poles)
Input power W 60 133.5
Output power W 30 66
Fan Speed
Lo (Cool) rpm 1240 - 1240 420 - 450
Me (Cool) rpm 1390 - 1390 —
Hi (Cool) rpm 1500 - 1500 770 - 785
SHi (Cool) rpm 1590 - 1590 —
Heat Exchanger
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Slit Fin
Row u Stage u FPI 2 u 15 u 21 2 u 34 u 17
Size (W u H u L) mm 810 u 315 u 25.4 814.8:834.8 u 714 u 25.4
Air Filter Type
Material Polypropelene —
Style One-touch —
