Note:
Unit CS-C7CK CU-C7CK
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 52.0 - 59.0
Rate Output W 15 30
Fan Speed Low rpm 780 - 780 —
Medium rpm 900 - 900 —
High rpm (1) 1,030 - 1,030 820 - 830
(3) 1,030 - 1,030 820 - 845
SuperHigh rpm 1,140 - 1,140 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 16
Size (W × H × L) mm 610 × 315 × 25.4 841 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GDID or ATMOS
M60 (260)
Refrigerant (R-22) g (oz) — 685 (24.2)
Thermostat Electronic Control —
Protection Device — 2 Stage Overload Protector
Capillary Tube Length mm — 655
Flow Rate l/min — 9.5
Inner Diameter mm — 1.4
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 25 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
•
Specifications are subject to change without notice for further improvement.
•
(1) — CS-C7CKP/CU-C7CKP5 (Europe & CIS).
•
(3) — CS-C7CKP-2/CU-C7CKP5-2 (Oceania).
7
CS-C7CKP CU-C7CKP5 / CS-C9CKP CU-C9CKP5 / CS-C9CKP CU-C9CKP6 / CS-C12CKP CU-C12CKP5 / CS-C12CKP CU-C12CK P6
