6
• Specifications are subject to change without notice for further improvement.
Heat Exchanger
Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium (Blue Coat)
Fin Type Slit Fin Louver Fin
Row / Stage
(Plate fin configuration, forced draft)
2 x 15 2 x 24
FPI 19 16
Size (W × H × L) mm 610 x 315 x 25.4 560 x 609.6 x 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
or ATMOS 56M
Refrigerant (R-22) g (oz) — 700 x 2 (24.7 x 2)
Thermostat ——
Protection Device — Overload protector
Capillary
Length mm — 680
Flow Rate l/min — 11.5
Inner Diameter mm — 1.5
Air Filter
Material
Style
P. P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 25 µF, 370/400 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 440 VAC 3.0 µF, 450 VAC
Unit Indoor unit Outdoor unit
