Panasonic CS-C9EKZW User Manual

5
2 Specifications
2.1. CS-C9EKZW CU-2C18EKH
Unit Indoor unit Outdoor unit
Performance Test Condition ISO 5151
Power Source (Phase, Voltage, Cycle)
ø Single
V
240 - 220
Hz
50
Cooling Capacity
kW (1 unit) 2.44 - 2.40 (2 units) 4.88 - 4.80
(BTU/h) (8,320 - 8,180) (16,600 - 16,400)
Moisture Removal
l/h (1 unit) 1.5 (2 units) 2.6
(Pint/h) (3.2) (5.5)
Airflow Method
OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume
Lo
m
3
/min (cfm)
5.7 (200) - 5.7 (200) —
Me
m
3
/min (cfm)
7.8 (274) - 7.8 (274) —
Hi
m
3
/min (cfm)
9.4 (332) - 9.4 (332) 32.6 (1,150) - 31.1 (1,100)
SHi
m
3
/min (cfm)
10.1 (357) - 10.1 (357) —
Noise Level dB (A) High 36 - 36, Low 26 - 26 High 55 - 53
Electrical Data
Input Power W
(1 unit) (2 units)
770 - 730 1,540 - 1,460
Running Current A
(1 unit) (2 units)
3.3 - 3.5 6.6 - 7.0
EER W/W (BTU/hW) (1 unit) 3.17 - 3.29 (10.8 - 11.2) (2 units) 3.17 - 3.29 (10.8 - 11.2)
Starting Current A 15.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 3-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G (gas side) ; 3/8”
L (liquid side) ; 1/4”
G (gas side) ; 3/8”
L (liquid side) ; 1/4”
Drain Inner diameter mm 12 —
Hose Length m 0.7 —
Dimensions
Height inch (mm) 11 - 1/32 (280) 25 - 21/32 (651)
Width inch (mm) 31 - 15/32 (799) 35 - 3/16 (893)
Depth inch (mm) 7 - 7/32 (183) 13 - 19/32 (345)
Net Weight lb (kg) 18 (8.0) 137 (62)
Compressor
Description —
Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 650
Fan Motor
Description Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% AS + Glass Fiber 20%
Type Induction (4-poles) Induction (6-poles)
Input W 29.3 - 26.3 134.6 - 118.8
Rated Output W 15 50
Fan Speed
Low rpm 730 - 730 —
Medium rpm 1,000 - 1,000 —
High rpm 1,210 - 1,210 760 - 720
SuperHigh rpm 1,300 - 1,300 —
