Panasonic CS-E12JKKW-1 - Page 9

9
Type Propeller
Material PP
Motor Type Induction (8 poles)
Input Power W -
Output Power W 38
Outdoor Fan
Speed Hi rpm 500 - 550
Moisture Removal L/h (Pt/h) 1.7 (3.6)
QLo m
3
/min (ft
3
/min)
Cooling : 12.5 (441)
Heating : 13.6 (479)
Lo m
3
/min (ft
3
/min)
Cooling : 13.7 (485)
Heating : 14.8 (526)
Me m
3
/min (ft
3
/min)
Cooling : 16.0 (565)
Heating : 17.0 (603)
Hi m
3
/min (ft
3
/min)
Cooling : 18.4 (650)
Heating : 19.2 (680)
Indoor Airflow
SHi m
3
/min (ft
3
/min)
Cooling : 18.9 (668)
Heating : 20.5 (725)
Outdoor Airflow Hi m
3
/min (ft
3
/min)
Cooling : 37.5 (1325)
Heating : 37.5 (1325)
Cooling : 41.6 (1470)
Heating : 41.6 (1470)
Control Device Capillary Tube
Refrigerant Oil cm
3
RB68A or Freol Alpha68M (400)
Refrigeration Cycle
Refrigerant Type g (oz) R410A, 1.18k (41.7)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 795 (31-5/16)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 235 (9-9/32) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 52 (115)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 10 (32.8)
Inner Diameter inch 13/20
Drain Hose
Length inch 25 - 29/50
Fin Material Aluminium (Pre Coat)
Fin Type Slit Fin
Row x Stage x FPI 2 x 15 x 21
Indoor Heat
Exchanger
Size (W x H x L) inch 1 x 12 1/25 x 31 9/10
Fin Material Aluminium (Blue coated)
Fin Type Corrugate Fin
Row x Stage x FPI 2 x 36 x 19
Outdoor Heat
Exchanger
Size (W x H x L) inch
1 11/25 x 29 19/25 x 24 21/50
24 21/50
Material Polypropelene
Air Filter
Type One-touch
Power Supply Indoor
Power Supply Cord A -
Thermostat -
Protection Device -
